Parameters
Designation
Unit
Max
Min
Preset
Ind.
019 -Pd
0 = Pedal in pos. -1 blocked in the seam. But with pedal in pos.
-2 sewing foot lifting is possible in the seam (function active
whenever the light barrier is On)
1 = With pedal in pos. -1 sewing foot lifting is blocked in the seam.
2 = Pedal in pos. –2, thread trimming disabled. (Function only if
parameter 009 = 1)
3 = Pedal in pos. –1 and –2 enabled in the seam.
4 = Pedal -1 and -2 locked in the seam (function only when
parameter 009 =1)
5 = Start seam end by with pedal -1
5
0
3
020 kLm
Clamp at the seam end On/Off
1
0
0
021 ckL
Run-out stitches clamp at the start of the seam
Stitches
254
0
2
022 SPO
0 = Chain suction until the end of count c2
1 = Chain suction at the seam end until pedal in pos. 0 (neutral)
2 = Chain suction until the drive is at standstill and the switch-off
start backtack (Parameter 237) has elapsed.
2
0
0
023 AFL
Automatic sewing foot lifting with pedal forward at the seam end, if
light barrier or stitch counting is On.
0 = Automatic foot lifting off
1 = Automatic foot lifting On
1
0
1
024 FSP
Coupled thread tension release and sewing foot lifting.
The function can be activated only with a thread trimmer that
depends on the angle.
0 = No coupling
1 = Coupled thread tension release and sewing foot at the seam
end with thread trimmer off
2 = Coupled thread tension release and sewing foot in the seam
and at the seam end with thread trimmer off
3 = Coupled thread tension release and sewing foot always
effective
3
0
0
025 tFS
Start counting (pa. 157) for thread tension release at the start of the seam
0 = Start counting at the start of the seam
1 = Start counting when the light barrier is covered
1
0
1
026 APd
Characteristic of the "analog pedal"
0 = Analog function off
1 = 12-level, like previous pedal function
2 = continuously variable
3 = 24-level
4 = 60-level
5 = 48-level
6 = 48 level / standing operation (SOP; foot control 304)i
6
0
4
027 plu
Area for setting + 1/2 of the analog pedal in percent
80
10
30
028 epd
0 = Function Off
1 = Pedal 2 release only from Pos. 1
0
1
0
030 rfw
Bobbin thread monitor
0 = Off
1 = Active with stop
2 = Active without stop
3 = Active with stop and start blockage after thread trimming
4 = As 1, but with display of remaining stitches
5 = As 2, but with display of remaining stitches
6 = As 3, but with display of remaining stitches
6
0
B
031 cfw
Number of stitches for bobbin thread monitor.
(The 3-digit value must be multiplied by 100).
255
0
B
037 Tu
Monitoring for FF1 signal in sec
60
0
0
0
038 1FH
Coupling with the 2nd thread tension release AFF1
0 = Off
1 = Coupling with FA
2 = Coupling with HP
3 = Coupling with FA and HP
3
0
0
039 1FL
Coupling with foot lifting with the 2nd thread tension AFF1
0 = Off
1 = Coupling with foot lifting in the seam
2 = Coupling with foot lifting at the seam end
3 = Coupling with foot lifting in the seam and at the seam end
3
0
0
040 3FB
Mode FlipFlop3
0 = Off
1 = Switched off when the foot is lifted
2 = Switched off during a reverse backtack
