7.19.2 Start and End Counts
Function with or without control panel
Parameters
End count (c2) at limited speed n4 until stop
Start count (c1) at limited speed n3 for chain suction
Count (c3) tape cutter at the start of the seam
End count (c4) for tape cutter at the seam end
Seam end in mode 7 through end count (c2) or (c4)
Stitch counting speed at the start of the seam
Stitch counting speed at the seam end
(c2)
(c1)
(c3)
(c4)
(mhE)
(n3)
(n4)
000
001
002
003
191
112
113
The following settings are possible for determining the seam end using parameter 191:
191 =0
Seam end after count c4 – tape cutter
191 =1
Seam end after count c2 – chain suction
7.20 Tape Cutter/Fast Scissors (Modes 6/7)
7.20.1 Tape Cutter/Fast Scissors in Mode 6
The signal tape cutter/fast scissors is issued only at the seam end. Furthermore, the manual tape cutter/fast
scissors function can be set. See also chapter "Manual Tape Cutter/Fast Scissors".
Function with or without control panel
Parameters
Tape cutter at the seam end On/Off
014
Output and Times for Tape Cutter
Function with or without control panel
Parameters
Delay time for output M3 (ST2/27) tape cutter AH
ON period for output M3 (ST2/27) tape cutter AH
(kd3)
(kt3)
284
285
 Parameter 232 must be set at "0" (tape cutter function).
 The delay time for the tape cutter is usually set at "0".
Output and Times for Fast Scissors
Function with or without control panel
Parameters
Delay time for output M3 (ST2/27) fast scissors AH1
ON period for output M3 (ST2/27) fast scissors AH1
Delay time for output M4 (ST2/36) fast scissors AH2
ON period for output M4 (ST2/36) fast scissors AH2
(kd3)
(kt3)
(kd4)
(kt4)
284
285
286
287
 Parameter 232 must be set at "1" (fast scissors function).
 The delay times for "fast scissors" are usually set at "0".
7.20.2 Tape Cutter/Fast Scissors in Mode 7
The signal tape cutter/fast scissors can be set separately for start and end counting. See also chapter "Manual
Tape Cutter/Fast Scissors".
Function without control panel
Control
Tape cutter/Fast scissors at the start of the seam On
Tape cutter/Fast scissors at the end of the seam On
Tape cutter/Fast scissors at the start and end of the seam On
Tape cutter/Fast scissors at the start and end of the seam Off
Segment 3 on
Segment 4 on
Segment s 3 and 4 on
LEDs 3 and 4 off
key + (S3)
 When using the V810 control panel, parameter 291 will automatically be set to slide-in strip "7" if 290 =7.
 When using the V820 control panel, parameter 292 will automatically be set to slide-in strip "5" if 290 =7.
Function with control panel
V810
V820
