Efka AB620A5035 - 7.34 Actuator; 8 Signal Test

- AB620A5035
- 50 -
 Independent of sewing, thus also when turning the handwheel manually
 Suitable e. g. for the connection of a counter
 A signal is issued at socket B18/1+6
7.34 Actuator
7.34.1 Analog actuator
Function with or without control panel
Parameters
Selectable pedal functions
Characteristic of the "analog pedal" EB401
(-Pd)
(APd)
019
026
The effect of pedal actuation on the drive functions can be set using parameter 019:
019 =0
Pedal in pos. -1 (slightly back) blocked in the seam. But with pedal in pos. -2 (all the way back)
sewing foot lifting is possible in the seam (function active whenever the light barrier is On).
019 =1
With pedal in pos. -1 (slightly back) sewing foot lifting is blocked in the seam.
019 =2
With pedal in pos. -2 (all the way back) thread trimming is blocked (function active whenever the
light barrier is On).
019 =3
The functions “pedal in pos. -1 (slightly back) and “pedal in pos -2 (all the way back) are active.
019 =4
The functions “pedal in pos. –1” (slightly back) and “pedal in pos. –2” (all the way back) are
blocked in the seam (function active whenever the light barrier is On).
019 =5
Start seam end by placing the portal at -1 (slightly back)
The characteristics of the “analog pedal” is adjustable with parameter 026:
026 =0
Analog function off
026 =1
12-level selected, like prior pedal function of the digital actuator.
026 =2
Continuously variable (i.e. for external potentiometer, without trimming function)
026 =3
24-level
026 =4
60-level
026 =5
48-level
026 =6
40-Step for SOP (standing operation)
8 Signal Test
Function with or without control panel
Parameters
Input and output test
(Sr4)
173
Function test of external inputs, multiple-function key bar and transistor power outputs with connected actuators
(e.g. solenoids and solenoid valves).
