Efka AB620A5035 - Supplier Level (Code No. 3112)

- AB620A5035 Instruction Manual
- 88 -
11.3 Supplier level (Code No. 3112)
Parameters
Designation
Unit
Max
Min
Preset
Ind.
200 t1
Start backtack until speed release after start backtack
ms
500
0
100
201 t2
Sewing foot switch-on start backtack after thread wiper
with half heelback
ms
2550
20
80
202 t3
Start start backtack after disabling the sewing foot lifting
signal
ms
500
0
50
203 t4
Time of full power of sewing foot lifting
ms
600
0
500
204 t5
Holding power for sewing foot lifting 1...100%
1% low holding power
100% high holding power
%
Pa.254
1
40
205 t6
Thread wiper time
ms
2550
0
120
206 t7
Start backtack from end of thread wiper until sewing foot
lifting On
ms
800
0
40
207 br1
Braking effect when varying the preset value ≤ 4 stages (indicated
values only with transmission ratio 1:1)
55
1
15
208 br2
Braking effect when varying the preset value ≥ 5 stages (indicated
values only with transmission ratio 1:1)
55
1
20
209 dFw
Thread wiper switch-on start backtack
ms
2550
0
0
210 tSr
Stop time for switching the stitch regulator in the
ornamental backtack
ms
500
0
140
211 tFL
Sewing foot lifting switch-on start backtack with thread
wiper off
ms
500
0
60
212 t10
Time of full power of backtacking or thread trimmer
forward
ms
600
0
500
213 t11
Holding power for backtacking or thread trimmer
backward 1...100%
1% low holding power
100% high holding power
%
Pa.255
1
40
215 Zrv
0 = Last counted forward segment in start backtack OFF
1 = Last counted forward segment in start backtack On
1
0
0
217 Sr
Number of operating hours before service in steps of 10
(operating hours recording enabled if set at “0”).
Std
99900
***)
00000
00000
218 SkL
Select custom machines
0 = No custom machine
1 = Model 204
2 = Big Bag
2
0
0
219 br3
Braking ramp for n < 350 when drive stopped
55
1
4
220 ALF
Accelerating power of the drive (indicated values only with
transmission ratio 1:1)
55
1
35
221 dGn
Speed gate 1
RPM
990
50
100
222 tGn
Speed gate damping period
ms
990
0
20
225 br4
Setting the braking curve for the light barrier and machine run
blockage (values only with transmission ratio 1:1)
55
1
20
229 dP2
Start backtack of heelback (-2)
ms
2000
0
0
232 USS
Overlock with fast scissors On/Off
1
0
0
233 c
Thread tension release switch-on start backtack
Stitches
254
0
0
234 pdo
Restart after machine run blockage via pedal 0 position
1
0
1
B
236 FLP
0 = Fl always permitted
1 = FI only permitted in position 2
2 = FI after cutting stored pedal plus ½ lifts storing, pedal
minus 1 switches stored FI on.
3 = Storage for standing actuation FBxxx
4 = Fl generally deactivated
5 = Stored foot lifting at the seam end can be deactivated
with pedal plus ½ and pedal minus 1.
5
0
0
B
237 tkS
Switch-off start backtack for chain suction at the seam
end, if parameter 022 = 2.
ms
2550
0
0
238 EnP
Software debouncing for all inputs:
0 = No debouncing
1 = Debouncing
1
0
1
239 FEL
Selection of the input function on socket B18/8
0 = Light barrier function, if 009 =1
All other functions as with parameter 240.
112
0
0
***)
The 4-digit value displayed must be multiplied by 10.
