- 41 -
Tape cutter/Fast scissors at the start of the seam On
Tape cutter/Fast scissors at the end of the seam On
Tape cutter/Fast scissors at the start and end of the seam On
Tape cutter/Fast scissors at the start and end of the seam Off
left-hand arrow above
key On
right-hand arrow above
key On
both arrows above key
On
both arrows above key
Off
Key 2
Key 4
The tape cutter signal can be influenced by parameter 020 in such a way that the signal remains on at the seam
end and is off when you begin sewing again after some run-out stitches, which can be set using parameter 021.
This action serves as clamp.
Function with or without control panel
Parameters
Clamp at the seam end (output ST2/27) On/Off (mode 7)
Run-out stitches from the clamp at the seam start (mode 7) or
Stitch count after the light barrier uncovered until the tape cutter is on (mode 15)
(kLm)
(ckL)
020
021
Output and Times for Tape Cutter
Function
Parameters
Delay time for output M3 (ST2/27) tape cutter AH
ON period for output M3 (ST2/27) tape cutter AH
(kd3)
(kt3)
284
285
 Parameter 232 must be set at "0" (tape cutter function).
 The delay time for the tape cutter is usually set at "0".
Output and Times for Fast Scissors
Function
Parameters
Delay time for output M3 (ST2/27) fast scissors AH1
ON period for output M3 (ST2/27) fast scissors AH1
Delay time for output M4 (ST2/36) fast scissors AH2
ON period for output M4 (ST2/36) fast scissors AH2
(kd3)
(kt3)
(kd4)
(kt4)
284
285
286
287
 Parameter 232 must be set at "1" (fast scissors function).
 The delay times for "fast scissors" are usually set at "0".
7.21 Manual Tape Cutter/Fast Scissors
Upon pressing an external key depending on the pre-selection of parameters 240...246, the tape cutter or fast
scissors can be enabled anywhere in the seam or at standstill.
See also chapter "Connection Diagram" in the List of Parameters!
