- AB620A5035 Instruction Manual
- 89 -
Supplier level (Code No. 3112)
Parameters
Designation
Unit
Max
Min
Preset
Ind.
240 in1
Selection of the input functions on socket ST2/7 for input 1
0 = No function
1 = Needle up/down
2 = Needle up
3 = Single stitch (basting stitch)
4 = Full stitch
5 = Needle to position 2
6 = Machine run blockage effective with open contact
7 = Machine run blockage effective with closed contact
8 = Machine run blockage unpositioned effective with open contact
9 = Machine run blockage unpositioned effective with closed
contact
10 = Automatic speed n12 without pedal (N.O. contact)
11 = Limited speed n12 pedal controlled
12 = Sewing foot lifting with pedal in position 0 (neutral)
13 = High lift for walking foot with speed limitation n10 (operational
mode not stored)
14 = “High lift walking foot” with speed limiting n10. Set parameter
137 to 1
15 = tape cutter/fast scissors: Function only in chainstitch and
overlock mode
16 = Intermediate backtack / intermediate stitch condensing
17 = Stitch regulator suppression / recall
18 = Unlocking the chain: Can be activated by pressing the key , but
will be executed only at the seam end
23 = No function
24 = Needle to position 2 (see instruction manual)
27 = Unlocking the chain: Function is performed upon pressing the
key
28 = External light barrier (according to setting of parameter 131)
30 = High lift for walking foot, if sewing foot is On
31 = Function “speed limitation bit0” (speed n11)
32 = Function “speed limitation bit1” (speed n10) (bit0 + bit1 =
speed n9)
33 = Speed n9 pedal controlled
34 = Automatic speed n9 can be suspended by pressing the pedal
to pos. 0 (neutral)
37 = Speed n12 pedal controlled (break contact)
38 = Automatic speed n12 without pedal (break contact [N.C.])
41 = Tape cutting only at machine standstill
42 = Enable hot thread chain cutting or sewing foot lifting. Function
only effective in mode 37
43 - 85 = No function
91 = Threading mode 66
101 = AFF1 ex.2. Thread tension release
102 = AFF2 ex. switch stitch length
103 = AFF3 example of an edge guide
104 = Manual lock automatic
109 = Part lift mode 66
110 = Machine run blockage in Pos. 2 at the seam end open
111 = Machine run blockage in Pos. 2 at the seam end close
112 = Foot lifting FlipFlop
113 – 117 No function
118 = Flipflop for running in nmax
119-123= No function
124 = Disable Strobel backtack
125-127 = No function
128 = Reset stitch counter
129 = Reset stitch counter for service
130 = Pedal -2 per external key
131-145= No function
145
0
0
241 in2
Selection of input function on socket ST2/11 for input 2
0 = No function
All other functions of the keys as with parameter 240
145
0
0
242 in3
Selection of input function on socket ST2/6 for input 3
0 = No function
All other functions of the keys as with parameter 240
145
0
0
