Parameters
Designation
Unit
Max
Min
Preset
Ind.
133 LSE
Thread trimming operation, when completing the seam after light
barrier sensing On/Off
1
0
1
134 SSt
Softstart On/Off
1
0
0
135 SrS
Ornamental backtack On/Off
1
0
0
136 FAr
0 = Trimming stitch backward Off
1 = Trimming stitch backward On with single end backtack
2 = Trimming stitch or positioning stitch always backward at the seam
end
2
0
0
Parameters
Designation
Unit
Max
Min
Preset
Ind.
137 hP
High lift for walking foot function activated/deactivated
1
0
0
139 nIS
Display of machine speed On/Off
1
0
0
140 dnE
Start backtack of seam end with pedal in pos. -2
ms
2550
0
0
141 SGn
Speed status for the seam with stitch counting
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 118) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 118)
3 = At fixed speed (Parameter 118) can be interrupted by full
heelback -2
4 = At fixed speed (Parameter 110) can be interrupted by full
heelback -2
4
0
0
142 SFn
Speed status for the free seam and for the seam with light barrier
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 118) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 118)
3 = At fixed speed (Parameter 118) can be interrupted by full
heelback (only for seams with light barrier).
3
0
0
143 kSA
Stitch counting at the start of the seam (e. g. chain suction)
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 112) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 112)
3 = At fixed speed (Parameter 112), can be suspended or
interrupted depending on the setting of parameter 019.
3
0
0
144 kSE
Stitch counting at the seam end (e. g. chain suction)
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111).
Fixed speed (Parameter 113) without influence by the pedal
(machine stop by pressing the pedal to the basic position).
1 = Limited speed controllable by the pedal up to the set limit
(Parameter 113)
2 = At fixed speed (Parameter 113), can be suspended or
interrupted depending on the setting of parameter 019.
3
0
0
145 Shv
Speed status for the manual backtack
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 109) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 109)
2
0
0
150 t8
Stitch correction of the double start backtack
(prolongation of the stitch regulator ON period /not
effective with ornamental backtack)
ms
500
0
0
151 t9
Stitch correction of the double end backtack (prolongation
of the stitch regulator ON period / not effective with
ornamental backtack)
ms
500
0
0
152 thP
High Lift Walking Speed Run-Out Time
ms
500
80
150
153 brt
Braking power at machine standstill
50
0
15
