- AB620A5035 Instruction Manual
Mode signal run
0 = Signal Off.
1 = Signal run On.
2 = Signal “run” enabled when the speed is >3000 RPM.
3 = Signal with pedal <> 0.
4 = Signal enabled only after motor synchronization (one rotation at
positioning speed after power On).
5 = Motor runs Eco with setting F-84 and F-85
6 = Motor runs the same as chain suction at the seam start / end
with counter F-084 and F-085
7 = The same as 6, however chain suction at the start of the seam
can be interrupted and with switch-off start backtack F-156
Switch-off start backtack for the signal “run” or signal with
pedal in pos. 0 (neutral)
Stitches until thread tension release Off after light barrier
covered at the start of the seam (Only in mode 7)
Direction of motor rotation
0 = Clockwise rotation
1 = Counterclockwise rotation
Start backtack speed whenever the backtack can be
interrupted by pedal in pos. 0 (neutral) (Parameter 164)
End backtack speed whenever the backtack can be
interrupted by pedal in pos. 0 (neutral) (Parameter 164)
Start and end backtack can be interrupted by pedal in
pos. 0 (neutral) On/Off
- See Section Fehler! Verweisquelle konnte nicht
gefunden werden. Setting the reference position
(Parameter 170)
See Section 6.10 Indication of the setting of the positions
See Section 8 Signal test
Language selection V860 control panel
1 = English
2 = German
Service routine for total operating hours display.
The process is as with display example of parameter 177.
Service routine for display of hours since the last service.
Display example for the operator control panel:
Press the E key again to restart routine, or press the P key twice to
return to operational status
Display example for the V810 control panel:
Display example for the V820 control panel:
