Mode 7 (overlock) parameter 232 = 0 (tape cutter) / parameter 018 = 0 (seam end with stop)
Mark
Function
Parameters
Control
V810
V820
FAm
LS
UoS
-Pd
kLm
SPO
tFS
LSS
kSA
kSE
mhE
PLS
kSL
USS
Mode 7
Counts c1, c2, c3 and c4
Sewing foot lifting at the seam end
Light barrier
Sequence “overlock mode with stop”
Function “pedal in pos. –2” blocked
Clamp at the seam end On
Chain suction at the seam end until pedal in pos. 0 (neutral)
Beginning of thread tension release at the start of the seam
Start blockage with light barrier uncovered
Stitch counting at the start of the seam at fixed speed n3
Stitch counting at the seam end at fixed speed n4
Seam end after count c2
Speed n5 after light barrier sensing
Chain suction On after light barrier compensating stitches
Tape cutter function
290 = 7
On
On
009 = 1
018 = 0
019 = 2
020 = 1
022 = 1
025 = 0
132 = 0
143 = 0
144 = 0
191 = 1
192 = 0
193 = 0
232 = 0
Key E/+
Key -
Key 1/2
Key 3
Key 1/4
Key 6
n1
n2
n3
n4
n5
n7
Positioning speed
Maximum speed
Speed for start counting
Speed for end counting
Speed after light barrier sensing
Trimming speed
110
111
112
113
114
116
c2
c1
c3
c4
LS
ckL
SFS
kd1/kd
kt1/kt2
kt3
kdF
End counting for chain suction
Start counting for chain suction
Start counting for tape cutter
End counting for tape cutter
Light barrier compensating stitches
Run-out stitches clamp at the start of the seam
Stitches from light barrier uncovered until end FSPL-E
Delay times of outputs M1/M
ON periods of outputs M1/M2
ON period of tape cutter
Switch-on delay of sewing foot lifting
000
001
002
003
004
021
157
280/282
281/283
285
288
