- AB620A5035 Instruction Manual
- 95 -
Parameters
Designation
Unit
Max
Min
Preset
Ind.
550 in12
Selection of input function on socket B22/3 for input 12
0 = No function
All other functions of the keys as with parameter 240
42
0
0
551 in13
Selection of input function on socket B22/4 for input 13
0 = No function
All other functions of the keys as with parameter 240
42
0
0
552 12L
Lower switching threshold of input IN12
%
100
0
30
553 12h
Upper switching threshold of input IN12
%
100
0
80
554 13L
Lower switching threshold of input IN13
%
100
0
30
555 13h
Upper switching threshold of input IN13
%
100
0
80
599 LrP
Last pilgrim backtack in positioning speed (n1) On/Off
1
0
1
808 M4´
Upper limit cycle M4 (2. Thread tension release)
%
100
0
100
820 FF1
FlipFlop1 On/Off
1
0
821 FF2
FlipFlop2 On/Off
1
0
822 FF3
FlipFlop3 On/Off
1
0
823 F1R
FlipFlop1 Reset at thread end On/ Off
1
0
824 F2R
FlipFlop2 Reset at thread end On/Off
1
0
825 F3R
FlipFlop3 Reset at thread end On/Off
1
0
828 cPL
Counter until puller lowers
255
0
829 MPL
0 = No function
1 = Always ventilate puller at the thread end
1
0
830 FF1
Selecting the output for flip-flop function AFF1
0 = No output selected
1 = M1
2 = M2
3 = M3
4 = M4
5 = M5
6 = M6
7 = M7
8 = M8
9 = M9
10 = M10
11 = M11
11
0
0
831 FF2
Selecting the output for flip-flop function AFF2
0 = No output selected
1 = M1
2 = M2
3 = M3
4 = M4
5 = M5
6 = M6
7 = M7
8 = M8
9 = M9
10 = M10
11 = M11
11
0
0
832 FF3
Selecting the output for flip-flop function AFF3
0 = No output selected
1 = M1
2 = M2
3 = M3
4 = M4
5 = M5
6 = M6
7 = M7
8 = M8
9 = M9
10 = M10
11 = M11
11
0
0
833 epd
0 = Function Off
1 = Pedal 2 release only from Pos. 1
0
1
0
