Chapter1Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents
and the overview of the software programs.
●
Disk contents and software overview
The disk includes application software programs for adjustment, and User’s Manual. Refer to “Readme.txt” or
the “read me” le on the disk for software startup procedures or le access procedures.
Contents Overview Windows Macintosh
A“Readme.txt”or“readme”le √ √
ColorNavigator
*1
Softwareforcalibratingmonitorcharacteristics
andgeneratingICCproles(forWindows)and
AppleColorSyncproles(forMacintosh).
(APCmustbeconnectedtothemonitorwith
thesuppliedUSBcable.)
√ √
ColorNavigatorElements
*2
Softwareforadjustingthecolorandbrightness
ofthemonitorwhilecomparingapicture
displayedonthemonitorwithaprintedpicture.
(APCmustbeconnectedtothemonitorwith
thesuppliedUSBcable.)
√ √
Screenadjustmentpatternles Usedwhenadjustingtheimageoftheanalog
signalinputmanually.
√ -
User’sManualofthismonitor(PDFle) √ √
*1 Only ColorNavigator Licensed models
*2 Only ColorNavigator Non-Licensed models
●
To use ColorNavigator / ColorNavigator Elements
The method of displaying the dened color gamut outside the normal gamut of the monitor can be set.
Attention
• If “ColorNavigator License” in the monitor information screen is “Not Registered”, the ColorNavigator license must be
purchased and registered to the monitor. For the purchase of the license, contact your local EIZO representative.
• ColorNavigator Elements can be used without a license.
Refer to the corresponding User’s Manual on the CD-ROM disk in order to install and use the software.
When using this software, you will need to connect a PC to the monitor with the supplied USB cable. For
details of the USB cable connection, see “7-3. Making Use of USB (Universal Serial Bus)” (page 48).

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
