Eizo ColorEdge CS230 User Manual

15
Chapter2AdjustingScreens
Chapter 2 Adjusting Screens
2-1. Compatible Resolutions
The monitor supports the following resolutions.
●
Analog Input (DVI-I)
Resolution Applicable Signals
Vertical scan
frequency
Dot clock
(Max.)
CS230 CX240
640×480 VGA 60Hz
149.0MHz
(CS230)
164.5MHz
(CX240)
√ √
720×400 VGATEXT 70Hz √ √
800×600 VESA 60Hz √ √
1024×768 VESA 60Hz √ √
1280×960 VESA 60Hz √ √
1280×1024 VESA 60Hz √ √
1600×1200 VESA 60Hz - √
1680×1050 VESACVT,VESACVTRB 60Hz √ √
1920×1080
*1
VESACVTRB 60Hz √ √
1920×1080
*1
CEA-861 60Hz √ -
1920×1200
*2
VESACVTRB 60Hz - √
●
Digital Input (DVI / DisplayPort)
Resolution Applicable Signals
Vertical scan
frequency
Dot clock
(Max.)
CS230 CX240
640×480 VGA 60Hz
149.0MHz
(CS230)
164.5MHz
(CX240)
√ √
720×400 VGATEXT 70Hz
√ √
800×600 VESA 60Hz √ √
1024×768 VESA 60Hz √ √
1280×960 VESA 60Hz √ √
1280×1024 VESA 60Hz √ √
1600×1200 VESA 60Hz - √
1680×1050 VESACVT,VESACVTRB 60Hz √ √
1920×1080
*1
VESACVTRB 60Hz √ √
1920×1200
*2
VESACVTRB 60Hz - √
●
Digital Input (HDMI)
• Video signal
- VGA / 480i,480p,1080i,720p,1080p: 60 Hz
- 576i,576p,1080i,720p,1080p: 50 Hz
- 1080p: 24 Hz, 25 Hz, 30 Hz
AgraphicsboardinconformancewiththeVESAandCEA-861standardsisrequired.
See“3-7.SettingSignalBandwidth”(page34).
*1 Recommended resolution (CS230)
*2 Recommended resolution (CX240)

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
