Chapter5PowerSavingFunctions
Chapter 5 Power Saving Functions
5-1. Setting Power Save
This function allows you to set the monitor into the power saving mode according to the PC status. When the
monitor has shifted to the power saving mode, the images on the screen are not displayed.
Attention
• Turning off the main power switch or unplugging the power cord completely shuts off power supply to the monitor.
• Devices connected to the USB downstream port work when the monitor is in power saving mode or when the power button
of the monitor is Off (except when “USB Power Save” is set to “On” in “5-5. Setting USB Power Save” (page 40)). Therefore,
power consumption of the monitor varies with connected devices even in the power saving mode.
• Five seconds before the monitor enters the power saving mode, it displays a preliminary message.
Procedure
1. Choose “PowerManager” from the Adjustment menu, and press
.
2. Choose “Power Save” from “PowerManager”, and press
.
3. Select “On” or “Off” with
or .
4. Press
to exit.
Power Saving System
Analog Signal Input
This monitor complies with the VESA DPM standard.
PC Monitor Power Indicator
On Operatingmode Blue
Powersaving
mode
STAND-BY
SUSPENDED
Off
Powersavingmode Orange
Digital Signal Input
- DVI signal input
This monitor complies with the “DVI DMPM” standard.
- DisplayPort signal input
This monitor complies with the “DisplayPort Standard V1.1a”.
PC Monitor Power Indicator
On Operatingmode Blue
Powersavingmode Powersavingmode Orange
HDMI Signal Input
The monitor enters the power saving mode after ve seconds in connection with the PC setting.
PC Monitor Power Indicator
On Operatingmode Blue
Powersavingmode Powersavingmode Orange
Exiting the power saving mode
If the monitor receives input, it automatically exits the power saving mode and returns to the normal display
mode.

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
