Chapter2AdjustingScreens
2-4. Adjusting Screens
●
Digital Signal Input
When digital signals are input, images are displayed correctly based on the preset data of the monitor, but if
you perform more advanced adjustment, see “2-3. Adjusting Color” (page 17) and subsequent pages.
●
Analog Signal Input
Attention
• As it takes about 30 minutes (CS230) / 7 minutes (CS240: under our measurement conditions) for the performance of
electrical parts to stabilize, adjust the monitor 30 minutes (CS230) / 7 minutes (CX240) or more after the monitor power
has been turned on.
• The Self Adjust (automatic screen adjustment) function does not work for the images under the resolution of 800 × 600
(SVGA).
• The self adjustment and auto adjustment functions work correctly when an image is fully displayed over the Windows
or Macintosh display area. They do not work properly in the cases below:
- when an image is displayed only on a part of the screen (command prompt window, for example)
- when a black background (wallpaper, etc.) is in use
Also, these functions cannot work properly in some graphic boards.
The monitor screen adjustment is used to suppress ickering of the screen or adjust screen position and screen
size correctly according to the PC to be used.
Note
• The self adjustment function works when all of the following conditions are satised:
- When a signal is input into the monitor for the rst time or when a resolution or vertical/horizontal scan frequency not
used before is set
If the screen is not displayed correctly even after performing the self adjustment operation, adjust the screen
according to the procedures on the following pages to use the monitor comfortably.
How to Set
1.
Perform the auto adjustment.
●
To adjust ickering, screen position, and screen size automatically
Procedure
1. Choose “Screen” from the Adjustment menu, and press
.
2. Choose “Analog Adjustment” from “Screen”, and press
.
3. Choose “Auto Adjustment” from “Analog Adjustment”, and press
.
Flickering, screen position, and screen size are corrected by the auto-adjustment function.
IfthescreenisnotdisplayedcorrectlyevenafterperformingAutoAdjustment,performtheadjustments
accordingtotheproceduresonthefollowingpages.Ifthescreenisdisplayedcorrectly,goto“Toenhance
outlineofimage”(page21).

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
