Eizo ColorEdge CS230 User Manual

54
Chapter7Reference
7-6. Preset Timing
The following table shows factory preset analog signal timing.
Attention
• Display position may be deviated depending on the PC connected, which may require screen adjustment using Adjustment
menu.
• If a signal other than those listed in the table is input, adjust the screen using the Adjustment menu.However, screen display
may still be incorrect even after the adjustment.
• When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the Adjustment
menu.
CS230
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×480 VGA 25.18 31.47 59.94 Negative Negative
720×400 VGATEXT 28.32 31.47 70.09 Negative Positive
800×600 VESA 40.00 37.88 60.32 Positive Positive
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1680×1050 VESACVT 146.25 65.29 59.95 Negative Positive
1680×1050 VESACVTRB 119.00 64.67 59.88 Positive Negative
1920×1080 VESACVTRB 138.50 66.59 59.93 Negative Positive
1920×1080 CEA-861 148.50 67.50 60.00 Positive Positive
CX240
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×480 VGA 25.18 31.47 59.94 Negative Negative
720×400 VGATEXT 28.32 31.47 70.09 Negative Positive
800×600 VESA 40.00 37.88 60.32 Positive Positive
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1600×1200 VESA 162.00 75.00 60.00 Positive Positive
1680×1050 VESACVT 146.25 65.29 59.95 Negative Positive
1680×1050 VESACVTRB 119.00 64.67 59.88 Positive Negative
1920×1080 VESACVTRB 138.50 66.59 59.93 Negative Positive
1920×1200 VESACVTRB 154.00 74.04 59.95 Positive Negative

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
