Eizo ColorEdge CS230 User Manual

51
Chapter7Reference
Environmental
conditions
Temperature Operating: 0˚Cto35˚C(32˚Fto95˚F)
Storage/Transportation: -20˚Cto60˚C(-4˚Fto140˚F)
Humidity Operating: 20%to80%R.H.(nocondensation)
Storage/Transportation: 10%to90%R.H.(nocondensation)
Airpressure Operating: 700hPato1060hPa
Storage/Transportation: 200hPato1060hPa
USB
Standard
USBSpecicationRevision2.0
Port
Upstreamport×2,Downstreamport×2
CommunicationSpeed
480Mbps(high),12Mbps(full),1.5Mbps(low)
Supplycurrent
Downstream: Max.500mA/1port
●
CX240
LCDPanel Size 24.1inch(610mm)
Type ColorTFT,IPS,LEDbacklight
Surfacetreatment HardCoating
Surfacehardness 3H
Viewingangles Horizontal178˚,vertical178˚(CR≥10)
Dotpitch 0.270mm
Responsetime Black-white-black: Approx.12ms
Gray-to-gray: Approx.7.7ms
Horizontalscan
frequency
Analog 26kHz-78kHz
Digital DVI/
DisplayPort
26kHz-78kHz
HDMI 15kHz-68kHz
Verticalscan
frequency
Analog 47.5Hz-61Hz(non-interlace)
Digital DVI/
DisplayPort
23.75Hz-63Hz(non-interlace)
(VGATEXT:69Hz-71Hz)
HDMI 23.75Hz-61Hz
FrameSynchronousmode 23.75Hz-30.5Hz,47.5Hz-61Hz
Resolution 1920dots×1200lines
Max.dotclock 164.5MHz
Max.displaycolor Approx.1073.74millioncolors(forDisplayPort10bit)
Displayarea(H×V) 518.4mm(20.4inch)×324.0mm(12.8inch)
Powersupply 100Vac-120Vac±10%,50/60Hz1.0A
200Vac-240Vac±10%,50/60Hz0.6A
Power
consumption
ScreendisplayOn 98Worless
Powersavingmode 0.5Worless (whenonlytheDVIsignalconnectorisconnected,
analogsignalinput,andnoUSBdeviceisconnected)
PowerOff 0.5Worless (whennoUSBdeviceisconnected)
MainpowerOff 0W
Inputsignalconnectors DVI-Iconnector(ApplicabletoHDCP)
DisplayPortconnector(StandardV1.1a,applicabletoHDCP)
HDMIconnector(ApplicabletoTypeA,HDCP)
Analoginputsignal(Sync) Separate,TTL,positive/negative
Analogsignaltransmissionsystem Analog,positive(0.7Vp-p/75Ω)
Digitalsignal(DVI/HDMI)transmission
system
TMDS(SingleLink)
Plug&Play Digital(DVI-I):VESADDC2B/EDIDstructure1.3
Digital(DisplayPort):VESADisplayPort/EDIDstructure1.4
Dimensions
(width)×(height)
×(depth)
Mainunit 575mm(22.6inch)×417mm–545mm(16.4inch-21.5inch)×245.5
mm(9.7inch)
Mainunit(withoutstand) 575mm(22.6inch)×398mm(15.7inch)×75mm(3inch)

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
