Eizo ColorEdge CS230 User Manual

37
Chapter4SelfCorrection
Chapter 4 SelfCorrection
This product is equipped with a built-in correction sensor. The conditions that have been adjusted using ColorNavigator
and the measurement device, or ColorNavigator Elements can be maintained.
As the adjustment targets or interval times for SelfCorrection are set in advance using ColorNavigator or
ColorNavigator Elements, the built-in correction sensor automatically executes regular display correction.
Attention
• To execute SelfCorrection, it is necessary to set the correction details. Set the target value in advance using ColorNavigator
or ColorNavigator Elements. Regarding ColorNavigator and ColorNavigator Elements, see “To use ColorNavigator /
ColorNavigator Elements” (page 10).
Note
• SelfCorrection can also be executed when there are no computer signals being input.
4-1. Executing SelfCorrection
Procedure
1. Choose “SelfCorrection” from the Adjustment menu, and press
.
2. Choose “Execute” from “SelfCorrection”, and press
.
The built-in correction sensor is activated, and SelfCorrection is executed.
Attention
• After selecting “Execute”, aging may be executed before the built-in correction sensor is executed.

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
