Eizo ColorEdge CS230 User Manual

34
Chapter3SettingMonitor
3-7. Setting Signal Bandwidth
The range of frequency and detection sensitivity of the change in signal can be switched.
Attention
• This function cannot be used with HDMI input.
Procedure
1. Press
to turn off the monitor.
2. Holding
down, press for at least two seconds to turn on the monitor.
The “Optional Settings” menu appears.
3. Choose “Signal Bandwidth” from “Optional Settings”, and press .
4. Choose the input signal to set with
or , and press .
5. Select “Normal” or “Wide” with
or , and press .
6. Press
twice.
7. Select “Finish” with
or .
8. Press
.
3-8. Switching USB Port Automatically
This function allows the input signal to link the USB upstream port when one monitor is connected to two PCs.
This can switch the USB port automatically according to the switch of the input signal. To calibrate one monitor
using two PCs, the USB cables do not need to be connected again. USB devices such as the mouse and keyboard
connected to one monitor can be used with two PCs.
Attention
• To switch the USB port to be used, two USB cables are required. Prepare cables.
• If a storage device such as a USB memory is connected to the monitor, remove the device before changing the setting.
Otherwise, data may be lost or damaged.
• The key arrangement of the keyboard cannot be changed.
Note
• When the “Input Selection” function is set to “Auto”, the USB port automatically switches according to the switch of the
input signal.
• The USB downstream port can be operated using the currently monitored PC.
Procedure
1. Choose “Tools” from the Adjustment menu, and press
.
2. Choose “USB Selection” from “Tools”, and press
.
3. Choose the input signal to set with
or , and press .
4. Select “USB-1” or “USB-2” with
or .
5. Press
to exit.

Eizo ColorEdge CS230 Specifications

General

3D	No
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Product type	PC monitor
Response time	10.5 ms
Display diagonal	23 \
Display technology	LED
Vertical scan range	47.5 - 61 Hz
Horizontal scan range	26 - 68 kHz
Viewable size diagonal	584 mm
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
USB hub version	2.0
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	0 - 90 °
Tilt angle range	0 - 30 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	54 W
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Certification	CUDO, TCO 6.0, TUV/S, TUV/Ergonomics, TUV/GS, cTUVus, CE, c-Tick, CB, VCCI-B, FCC-B, ICES-003-B, RoHS, WEEE, GOST-R
Product color	Black
Market positioning	Graphics design
Cables included	AC, DVI, USB
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	245.5 mm
Height (with stand)	526.5 mm
Weight (with stand)	7500 g
Depth (without stand)	75 mm
Width (without stand)	544 mm
Height (without stand)	353 mm
Weight (without stand)	4800 g
