Elan s86a - Appendix A: Specifications

E L A N H O M E S Y S T E M S
INSTALLATION MANUAL
Page 68 © ELAN Home Systems 2009 • All rights reserved.
S86A
Appendix A: Specifications
Table A-1 shows the equipment specifications for the S86A Multi-Room Integrated Controller.
Table A-1 S86A Multi-Room Integrated Controller Specifications
Item Description
System Multi-Source/Multi-Zone Integrated Controller
Source Inputs
Input Sensitivity
Input Impedance
0-2V RMS
47K Ohms
Pre-Amplifier Output
Max. Output Power
Frequency Response
THD+Noise(@1KHz)
Signal-to-Noise (A Weighted)
Crosstalk (Zone to Zone)
Output Impedance
6dB
20Hz to 20kHz, +/-0.5dB
< 0.02%
>95dB
>105dB
600 Ohms
Amplifier Output
Max. Output Power
Speaker Impedance
Frequency Response
THD+Noise(@1KHz
Signal-to-Noise (A Weighted)
Crosstalk (Zone to Zone)
40W @ 8 Ohms
8 Ohms
20Hz to 20kHz, +/-1dB
< 0.02%
>95dB
>70dB
Music On Hold Output
Output Impedance
Max Output Level:
600 Ohms
+6dB
Page & Doorbell Input
Input Sensitivity
Input Impedance
0-2V RMS
47k Ohms
Video
Gain
Bandwidth (-3dB)
Gain Flatness (1dB)
Input Impedance
Output Impedance
Crosstalk
Unity
12MHz
6MHz
75 Ohms
75 Ohms
>40dB@3.58MHz
