Elan s86a - AC Power Connector

E L A N H O M E S Y S T E M S
INSTALLATION MANUAL
© ELAN Home Systems 2009 • All rights reserved. Page 59
S86A
AC Power Connector
The AC Power Connector connects to a 120VAC (240VAC for International model) power source to provide power to
the S86A Multi-Room Integrated Controller (see Figure 3-56).
120VAC 60Hz.
400W
Figure 3-56: AC Power Receptacle
