EPIR3 User Manual v1.3
3. HOW TO MANAGE THE WIRELESS DEVICES
IMPORTANT: Before you continue, rst follow the entire section 2. QUICK START GUIDE and prepare the
system for use as described.
OVERVIEW
Your EPIR3 has a built-in wireless module. This section tells you how to pair and remove a wireless device using
your PC and ELDES Conguration Tool as well as briey describing every available wireless device which can oper-
ate together with your EPIR3 system.
It is possible to connect up to 16 wireless devices to the EPIR3 system. This includes the following:
• EWP2 – wireless PIR sensor (motion detector).
• EWD2 - wireless magnetic door contact/shock sensor/ood sensor.
• EWS3 – wireless indoor siren.
• EWS2 – wireless outdoor siren.
• EWK1 and EWK2/EWK2A – wireless keyfob.
• EKB3W – wireless LED keypad.
• EW2 – wireless zone and PGM output expansion module (up 8 devices supported).
• EWF1/EWF1CO - wireless smoke/CO detector.
• EWR2 - wireless signal repeater.
You can also attach more devices which are not part of the ELDES wireless range by using expansion module EW2
with 4 zones and 2 programmable outputs
Main features of built-in wireless module:
• Up to 16 ELDES wireless devices per one EPIR3 unit;
• Two-way wireless communication;
• Supervised communication link with congurable self-test period;
• Maximum wireless connection range is 150m (492.13ft) in open areas, within a building wireless range will
be up to 30m (98.43ft), depending on building construction.
For more details on technical specications and installation of the wireless devices, please refer to RADIO SYS-
TEM INSTALLATION AND SIGNAL PENETRATION manual and the latest user manual of the wireless device
located at www.eldes.lt/download
The wireless devices can operate at a range of up to 30m (98.43ft) from the alarm system unit while inside the
building and at up to 150m (492.13ft) range in open areas. The wireless connection is two-way and operates in
one of four available channels in ISM868 (EU version) / ISM915 (US version) non-licensed band.
EKB3W, EW2, EWP2, EWS21, EWS3, EWF1/EWF1CO::
• First 360 attempts after the device startup (reset) - every 10 seconds.
• The rest of attempts - every 1 minute.
EWD2:
