EPIR3 User Manual v1.3
• First 360 attempts after the device startup (reset) - every 10 seconds.
• The rest of attempts - every 2 minutes.
Once the wireless device is paired, it will attempt to exchange data with ESIM364 system. Due to battery saving
reasons, all ELDES wireless devices operate in sleep mode. The data exchange will occur instantly if the wireless
device is triggered (zone alarm or tamper alarm) or periodically when the wireless device wakes up to transmit the
supervision signal, based on Test Time value, to the system as well as to ac cept the queued up command (if any)
from the system. By increasing the Test Time period, EWS2/EWS3 siren response time will decrease. Example:
The alarm occurred at 09:15:25 and the system queued up the command for EWS3 siren to start sounding. By
default, Test Time value of EWS3 siren is 7 seconds, therefore EWS3 siren will sound at 09:15:32.
By default, the Test Time period is as follows (customizable):
• EKB3W: every 60 seconds.
• EW2, EWP2, EWF1/EWF1CO, EWD2: every 30 seconds
• EWS2, EWS3: every 7 seconds.
To set a dierent Test Time value, please refer to ELDES Conguration Tool software.
NOTE: Test Time aects the wireless device pairing process due to the alarm system listening for the incoming
data from the wireless device. The system pairs with the wireless device only when the rst data packet is
received.
NOTE FOR EKB3W: In comparison with other ELDES wireless devices, EKB3W keypad features some exceptions
regarding the wireless communication. For more details on EKB3W keypad wireless communication and back-light
timeout, please refer to 3.3.1. Sleep mode, how to wake up EKB3W and view system alarms or faults.
3.1. How to pair a wireless device with the system
IMPORTANT: Before you continue, rst ensure the EPIR3 is powered up and connected to your PC via the
USB cable.
1. Turn on the wireless device by following the instructions provided in the user manual of the wireless device.
2. Run ELDES Conguration Tool software and left-click on the USB CONNECTION / Open Conguration button.
