EPIR3 User Manual v1.3
Keys Functionality
[BYPS] Zone bypass mode
[CODE] System fault list / violated high-numbered zone indication / violated high-numbered tamper
indication
[*] Clear typed in characters
[#] Conrm (enter) command
[0] ... [9] Command typing
[STAY] Manual system arming in Stay mode
[INST] 1st character for Conguration mode activation/deactivation command
The green LED READY indicates that no zones or tampers are violated and the system is ready for arming. LED
SYSTEM lights up or ashes in case of zone violation or if system faults are present. The alarm system cannot be
armed until the fault is corrected or violated zone (-s) is restored, bypassed or set up to operate under Force mode.
The system can still be armed even when the following faults are present:
• backup battery problem;
• mains power failure;
• date & time not set;
• GSM connection problem.
Audio Indication
The built-in buzzer uses two types of sound signals – three short beeps and one long beep. Three short beeps stand
for successfully carried out conguration command, one long beep – for inva lid conguration command. In addition,
the buzzer will continuously provide short beeps for 10 seconds (by default) in case of alarm when the violated zone
or tamper is of the associated EKB3W keypad.
Visual Indication
EKB3W keys have a back-light and in case of alarm the keypad back-light turns on and lasts for 10 seconds (by
default) if the violated zone or tamper is of the associated EKB3W keypad. For battery power saving reasons the
back-light and LED light lasts for 10 seconds after the last key-stroke. However, this duration is congurable.
3.3.1. Sleep mode, how to wake up EKB3W and view system alarms or faults
Once EKB3W is paired, it will attempt to exchange data with the system. The communication process follows this
pattern:
Sleep mode. Due to battery power saving reasons, most of the time EKB3W keypad operates in sleep mode and
periodically (by default – every 60 seconds) transmits the supervision signal, identied as Test Time, to the EPIR3
system. When the keypad operates in the sleep mode, only the transmitter remains operational, while the receiver
as well as the the LED indicators and the back-light are switched OFF. However, when the keypad transmits the
supervision signal to the system, it will NOT activate its buzzer and/or the LED indicators.
How to wake up EKB3W and view system alarms, faults. When any EKB3W key is pressed, the keypad LED
