ADL 2010 / 01 42/57 599 72 63-27
13.4 Door microswitch latch (certain models only)
With a screwdriver, press on the locking hook and
turn it in the direction indicated by the arrow.
13.5 Door microswitch (certain models only)
1. Unfasten the fixing screw.
2. Extract it slightly and move it to the left until it
reaches the connector.
3. Disconnect the connector and fasten it to the
front with a piece of sticking tape to prevent it
from going back into the machine.
