1 PURPOSE OF THIS MANUAL
The purpose of this manual is to provide technicians (who already have the basic skills required to carry out
repairs on tumble dryers) with technical information on this condensation tumble dryer with electronic
control.
The electronic control is made up of a main circuit board with integrated selector - certain models have an
LCD display. They are supplied ready-assembled and tested by the manufacturer.
The manual deals with the following topics:
• General characteristics.
• Control panel and drying programmes.
• Description of operation.
• Drying circuit.
• Electrical components and wiring diagram.
• Guide to diagnostics.
• Alarms.
• Access.
2 WARNINGS
ATTENZIONE
Ö Any work on electrical appliances must only be carried out by qualified
technicians.
Ö Before accessing internal parts of the appliance, always make sure the plug
has been removed from the power socket.
2.1 Installation
The appliance must be installed so that it is perfectly level (using a spirit level).
The feet must never be removed. A gap must always be left between the bottom of the tumble dryer and the
floor to prevent the appliance from overheating.
