3.4 TECHNICAL DATA
Elmasteam 8
Mains voltage (Vac) 220 - 240
Mains frequency (Hz) 50 / 60
Mains Supply Connection Shockproof
safety plug 1
phase
Mains impedance maximum
(Ohm)
0.155
Power consumption
maximum (W)
3120
Sound pressure level at 8 bar
dBA)
93
Pressure in the pressure
vessel (bar)
8
Pressure vessel volumes
(litres)
5
Maximum filling volume
(litres)
3.8
* Heating up time (minutes) 20
Steam temperature outlet Approximately
160 °C
Steam temperature in the
boiler
Approximately
185 °C
Dimensions without manual
unit bracket and fixed nozzle
W x D x H (mm)
285 x 350 x 520
Material housing Stainless steel
Pressure vessel Stainless steel /
aluminium bronze
Weight (kg) Approximately 20
* Approximate value for maximum-filled pressure vessel
