Elma Elmasteam 8 basic - Assembling the Foot Switch (Option)

Commissioning
© Elma Schmidbauer GmbH BA_Elmasteam_8_Vers.07.2016
31
4.2.1 Assembling the Foot Switch (option)
1. The plug for the foot switch will be screwed onto the
connection (Figure 4.2.1.1-A).
Observe the plug direction when plugging in (Figure 4.2.1.2-B)!
The plug clicks during rotation!
Manually tighten the plug until it stops turning (Figure 4.2.1.3-
C)
Figure 4.2.1.1: Connection for the Foot Switch (Rear panel)
Figure 4.2.1.2: Aligning the plug (B)
Figure 4.2.1.3: Plug for the Foot Switch (Rear side of the device)
Assembling the
Foot Switch
A
C
B
