Commissioning
© Elma Schmidbauer GmbH BA_Elmasteam_8_Vers.07.2016
35
Figure 4.4.2: Device connection (D) for water supply (water pipe)
Figure 4.4.3: Connected water hose
INFORMATION
Inspect the secure fixing for the fixed-water
connection!
Maintain a proper and secure fixing for the water
hose.
Inspect the connections (Figure 4.4.3-E + F) for
tightness.
assembly
E
F
D
