Device filling/emptying
46
BA_Elmasteam_8_Vers.07.2016 © Elma Schmidbauer GmbH
Figure 6: Operating Displays
Warning illuminates/flashes red
Filling Level illuminates/flashes blue
Service (Descaling) - illuminates/flashes orange
Gauge Scale of values illuminates/flashes green
INFORMATION
Operation Displays, Gauge
• Observe the gauge display! The device remains
under pressure as long as one segment is
illuminated on the value scale on the gauge.
A
B
C
D
