MES53xx, MES33xx, MES23xx Ethernet Switch Series 116
{gigabitethernet gi_port |
tengigabitethernet te_port |
fortygigabitethernet fo_port |
port-channel group |
vlan vlan_id}
te_port: (1..8/0/1..24);
fo_port: (1..8/0/1..4);
group: (1..16);
vlan_id: (1..4094)
command assigns the associated uplink interface used in
routing.
EXEC mode commands
Command line prompt in the EXEC mode is as follows:
console#
Table 5.110. EXEC mode commands
Command
Value/Default value
Action
show ip mroute
[ip_multicast_address
[ip_address]] [summary]
-
This command allows you to view multicast group lists. You can
select a group by group address or multicast data source
address.
- ip_multicast_address - multicast IP address;
-ip_address– source IP address;
- summary - brief description of each record in the multicast
routing table.
show ip igmp-proxy interface
[vlan vlan_id |
gigabitethernet gi_port |
tengigabitethernet te_port |
fortygigabitethernet fo_port |
port-channel group]
vlan_id: (1..4094);
gi_port: (1..8/0/1..48);
te_port: (1..8/0/1..24);
fo_port: (1..8/0/1..4);
group: (1..16)
Information about the status of IGMP-proxy for specific
interfaces.
console#show ip igmp-proxy interface
* - the switch is the Querier on the interface
IP Forwarding is enabled
IP Multicast Routing is enabled
IGMP Proxy is enabled
Global Downstream interfaces protection is enabled
SSM Access List Name: -
Interface Type Interface Protection
vlan5 upstream
vlan30 downstream default
7.3 Multicast routing. PIM protocol
Protocol-Independent Multicast protocols for IP networks were created to address the problem of
multicast routing. PIM relies on traditional routing protocols (such as, Border Gateway Protocol) rather
than creates its own network topology. It uses unicast routing to verify RPF. Routers perform this
verification to ensure loop-free forwarding of multicast traffic.
RP (rendezvous point) is a rendezvous point where multicast source are registered and create a
route from source S (self) to group G: (S,G).
BSR (bootsrtap router) is a mechanism for gathering information about RP candidates, creating an
RP list for each multicast group and sending it with a domain. IPv4 multicast routing configuration.
Global configuration mode commands
Command line prompt in the global configuration mode is as follows:
