MES53xx, MES33xx, MES23xx Ethernet Switch Series 103
specific time period, the voice vlan will be removed from this
port.
no voice vlan

Restore the default value.
voice vlan cos cos [remark]
cos: (0-7)/6
Set COS to mark the frames belonging to Voice VLAN.
no voice vlan cos
Restore the default value.
voice vlan id vlan_id
vlan_id: (1..4094)
Set the VLAN identifier for Voice VLAN
no voice vlan id
Remove the VLAN identifier for Voice VLAN
Before you can remove the VLAN identifier, disable
the voice vlan function on all ports.
voice vlan oui-table {add
oui | remove oui} [word]
word: (1..32) characters
Allow you to edit OUI table.
- oui - first 3 bytes of the MAC address
- word - OUI description.
no voice vlan oui-table
Remove all user changes made to the OUI table.
Ethernet interface configuration mode commands
Command line prompt in the Ethernet or port group interface configuration mode is as follows:
console(config-if)#
Table 5.91. Ethernet interface configuration mode commands
Command
Value/Default value
Action
voice vlan enable
-/disabled
Enable Voice VLAN for the port.
no voice vlan enable
Disable Voice VLAN for the port.
voice vlan cos mode {src |
all}
-/src
Enable traffic marking for all frames or for the source only.
no voice vlan cos mode
Restore the default value.
7.2 Multicast addressing
7.2.1 Multicast addressing rules
These commands are used to set multicast addressing rules on the link and network layers of the
OSI network model.
VLAN interface configuration mode commands
Command line prompt in the VLAN interface configuration mode is as follows:
console(config-if)#
Table 5.92. VLAN interface configuration mode commands
Command
Value/Default value
Description
bridge multicast mode
{macgroup | ipv4-group |
ipv4-src-group}
-/mac-group
Specify the multicast data transmission mode.
- mac-group - multicast transmission based on VLAN and MAC
addresses;
-ipv4-group - multicast transmission with filtering based on
VLAN and the recipient's address in IPv4 format;
- ip-src-group - multicast transmission with filtering based on
VLAN and the sender's address in IPv4 format
no bridge multicast mode
Set the default value.
bridge multicast address
{mac_multicast_address |
ip_multicast_address} [{add |
remove}
{gigabitethernet gi_port |
tengigabitethernet te_port |
fortygigabitethernet fo_port |
port-channel group}]
gi_port: (1..8/0/1..48);
te_port: (1..8/0/1..24);
fo_port: (1..8/0/1..4);
group: (1..16)
Add a multicast MAC address to the multicast addressing table
and statically add or remove interfaces to/from the group.
- mac_multicast_address - multicast MAC address;
- ip_multicast_address - multicast IP address;
- add – add a static subscription to a multicast MAC address of
a range of Ethernet ports or port groups.
- remove - remove the static subscription to a multicast MAC
address;
Interfaces must be separated by “–” and “,”.
