MES53xx, MES33xx, MES23xx Ethernet Switch Series 65
Internal MAC Rx Errors
The number of frames for which a reception fails due to an internal MAC receive
error.
Symbol Errors
For an interface operating at 100Mbps, the number of cases there was as invalid
data symbol when a valid carrier was present.
For an interface operating in 1000Mbps half-duplex mode, the number of cases
when receiving instrumentation was busy for a time period equal or greater than
the slot size (slotTime) during which there was at least one occurrence of an event
that caused the PHY to indicate Data reception error or Carrier extend error on the
GMII.
For an interface operating in 1000Mbps full-duplex mode, the number of times
when receiving instrumentation was busy for a time period equal or greater than
the minimum frame size (minFrameSize), and during which there was at least one
occurrence of an event caused the PHY to indicate Data reception error on the GMII.
Received Pause Frames
The number of control MAC frames with PAUSE operation code received.
Transmitted Pause
Frames
The number of control MAC frames with PAUSE operation code sent.
5.9.2 VLAN interface configuration
VLAN configuration mode commands
Command line prompt in the VLAN configuration mode is as follows:
console# configure
console(config)# vlan database
console(config-vlan)#
This mode is available in the global configuration mode and designed for configuration of VLAN
parameters.
Table 5.32. VLAN configuration mode commands
Command
Value/Default value
Action
vlanVLANlist
VLANlist: (2..4094)
Add a single or multiple VLANs.
no vlan VLANlist
Remove a single or multiple VLANs.
map protocol protocol
[encaps] protocols-group
group
protocol: (ip, ipx, ipv6, arp,
(0600-ffff (hex)}*);
encaps: (ethernet, rfc1042,
llcOther);
ethernet group:
(1..2147483647);
Tether the protocol to the associated protocol group.
no map protocol protocol
[encaps]
Remove tethering.
* - protocol number (16 bit).
map mac mac_address
{host | mask} macs-group
group
mask: (9..48)
Tether a single or a range of MAC addresses to MAC address
group.
no map mac mac_address
{host | mask}
Remove tethering.
VLAN interface (interface range) configuration mode commands
Command line prompt in the VLAN interface configuration mode is as follows:
console# configure
console(config)# interface {vlan vlan_id |range vlan VLANlist}
console(config-if)#
This mode is available in the global configuration mode and designed for configuration of VLAN
interface or VLAN interface range parameters.
