ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 64
Ch InUcastPkts InMcastPkts InBcastPkts InOctets
---------------- ------------ ------------ ------------ ------------
Po1 111 0 0 9007
Ch OutUcastPkts OutMcastPkts OutBcastPkts OutOctets
---------------- ------------ ------------ ------------ ------------
Po1 0 6 3 912
Alignment Errors: 0
FCS Errors: 0
Single Collision Frames: 0
Multiple Collision Frames: 0
SQE Test Errors: 0
Deferred Transmissions: 0
Late Collisions: 0
Excessive Collisions: 0
Carrier Sense Errors: 0
Oversize Packets: 0
Internal MAC Rx Errors: 0
Symbol Errors: 0
Received Pause Frames: 0
Transmitted Pause Frames: 0
 Show jumbo frame settings for the switch:
console# show ports jumbo-frame
Jumbo frames are disabled
Jumbo frames will be disabled after reset
Table 5.31. Description of counters
Counter
Description
InOctets
The number of bytes received.
InUcastPkts
The number of unicast packets received.
InMcastPkts
The number of multicast packets received.
InBcastPkts
The number of broadcast packets received.
OutOctets
The number of bytes sent.
OutUcastPkts
The number of unicast packets sent.
OutMcastPkts
The number of multicast packets sent.
OutBcastPkts
The number of broadcast packets sent.
Alignment Errors
The number of frames that failed integrity verification (whose number of bytes
mismatches the length) and frame check sequence validation (FCS).
FCS Errors
The number of frames whose byte number matches the length that failed frame
check sequence (FCS) validation.
Single Collision Frames
The number of frames involved in a single collision, but transmitted successfully.
Multiple Collision Frames
The number of frames involved in multiple collisions, but transmitted successfully.
Deferred Transmissions
The number of frames for which the first transmission attempt was delayed due to
busy transmission media.
Late Collisions
The number of cases when collision is identified after transmitting the first 64 bytes
of the packet to the communication link (slotTime).
Excessive Collisions
The number of frames that were not sent due to excessive number of collisions.
Carrier Sense Errors
The number of cases when the carrier control state was lost or not approved during
the frame transmission attempt.
Oversize Packets
The number of received packets whose size exceeds the maximum allowed frame
size.
