MES53xx, MES33xx, MES23xx Ethernet Switch Series 167
Table 5.189. Global configuration mode commands
The agent is disabled by
default.
Enable DHCP Relay agent feature for the switch.
Disable DHCP Relay agent feature for the switch.
ip dhcp relay address
ip_address
You can configure up to 8
servers.
Specify the IP address of an available DHCP server for the
DHCP Relay agent.
no ip dhcp relay address
[ip_address]
Remove an IP address from the list of DHCP servers for the
DHCP Relay agent.
VLAN interface configuration mode commands
Command line prompt in the VLAN interface configuration mode is as follows:
console# configure
console(config)# interface vlan vlan_id
console(config-if)#
Table 5.190. VLAN and Ethernet interface configuration mode commands
The agent is disabled by
default.
Enable DHCP Relay agent feature on the interface.
Disable DHCP Relay agent feature on the interface.
EXEC mode commands
Command line prompt in the EXEC mode is as follows:
console#
Table 5.191. EXEC mode commands
Show the DHCP Relay agent feature configuration for the switch
and for interfaces separately, and the list of available servers.
Examples of command usage
Show DHCP Relay agent feature status:
console# show ip dhcp relay
DHCP relay is Enabled
DHCP relay is not configured on any vlan.
Servers: 192.168.16.38
Relay agent Information option is Enabled
11.1 PPPoE Intermediate Agent (PPPoEIA) configuration
PPPoEIA function is realized in accordance with the requirements of the DSLForumTR-101
document and designed to use it on the switches operating at the access level.
Function allows you to add information describing access interface in the PPPoEDiscovery packets.
It is required for user interface authentication on the access server (BRAS, Broadband Remote Access
Server).
PPPoEIA function realization provides the additional capabilities to control protocol messages by
assigning the proxy interfaces.
Global configuration mode commands
