MES53xx, MES33xx, MES23xx Ethernet Switch Series 168
Command line prompt in the global configuration mode is as follows:
console(config)#
Table 5.192– Global configuration mode commands
Command
Value/Default value
Action
pppoe intermediate-agent
-/disabled
Permit PPPoE Intermediate Agent operation.
no pppoe
intermediateagent
Forbid PPPoE Intermediate Agent operation.
pppoe intermediate-agent
timeout seconds
seconds :( 0..600) /300
Set a timeout of the user inactivity.
no pppoe
intermediateagent
timeout
Recovery the default settings.
pppoe intermediate-agent
format-type access-node-id
word
word: (1..32) characters
/device identifier is not
assigned.
Setting the device identification line.
no pppoe
intermediateagent
format-type access-node-id
Recovery the default settings.
pppoe intermediate-agent
format-type
genericerrormessage
word
word: (1..128) characters
/PPPoE Discover packet is
too large to process.
Setting the message text about error of the packet (MTU)
oversize. PPPoE IA transmits this packets by using PADO or
PADS packets.
Note: If there is space symbol in the message it should be
enclosed in quotation marks.
nopppoe
intermediateagent
format-type
genericerrormessage
Recovery the default settings.
pppoe intermediate-agent
format-type option[sp |
sv | pv | spv] delimeter
delim
delim: (.,:#/)/format in
accordance with TR-101:
slot / port : vlan
Setting the parameter set and spacer between them which are
used for forming the circuit-id suboption.
The following symbolic notations are used in the command:
- sp – slot + port;
- sv – slot + vlan;
- pv – port + vlan;
- spv – slot + port + vlan;
no pppoe
intermediateagent
format-type option
Recovery the default settings.
Interface configuration mode commands
Command line prompt in the interface configuration mode is as follows:
console(config-if)#
Table 5.193 – The list of the commands for the Ethernet configuration mode and port groups
Command
Value/Default value
Action
pppoe intermediate-agent
/deny
Permit PPPoE Intermediate Agent operation on the
interface.
no pppoe intermediateagent
Deny PPPoE Intermediate Agent operation on the
interface.
pppoe intermediate-agent
format-type circuit-idcircuit_id
circuit_id: (1..63)
characters
Assigning the circuit-id identifier added by switch.
Identifier assigned to a command totally redefines the
identifier that is calculated based on the access-node-id
and option/delimeter global parameters.
no pppoe intermediateagent
format-type circuit-id
Recovery the setting based on the access-node-id and
option/delimeter global parameters.
pppoe intermediate-agent
format-type remote-idremote_id
remote_id: (1..63)
characters /switch MAC
address.
Assigning the remote-id identifier added by switch.
Identifier must be configured on all the switch’s interfaces
where PPPoE IA operates.
no pppoe intermediateagent
format-type remote-id
Recovery the default setting.
