MES53xx, MES33xx, MES23xx Ethernet Switch Series 14
SSH server
SSH server functionality allows SSH clients to establish secure connection to the
device for management purposes.
Macrocommand
support
This feature allows the user to create sets of commands—macrocommands—and
user them to configure the device.
2.2.8 Additional Features
The table lists additional device features.
Table 2.8. Additional functions
Virtual Cable Test (VCT)
The network switches are equipped with the hardware and software tools that
allow them to perform the functions of a virtual cable tester (VCT). The tester
check the condition of copper communication cables.
Optical transceiver
diagnostics
The device can be used to test the optical transceiver. During testing, the device
monitors the current, power voltage and transceiver temperature. To use this
function, these features should be supported by the transceiver.
Green Ethernet
This mechanism reduces power consumption of the switch by disabling inactive
electric ports.
2.3 Main specifications
Table 2.9 lists main specifications of the switch.
Table 2.9. Main specifications
General parameters
Packet processor
MES5324
Marvell 98CX8129-A1 (Hooper)
MES3324F
Marvell 98DX3336-A1 (PonCat3)
MES2324,
MES2324B,
MES2324FB
MES2348B
MES2308
MES2308P
Marvell 98DX3236-A1 (AlleyCat3)
Interfaces
MES5324
1x10/100/1000Base-T (OOB), 1x10/100/1000Base-T (Management),
24x10G Base-X(SFP+)/1000Base-X (SFP), 4x40G Base-SR4/LR4 (QSFP)
MES3324F
1x10/100/1000Base-T (OOB),
20x1000 Base-X (SFP), 4x(10G Base-X(SFP+)/1000Base-X (SFP),
4x10/100/1000 Base-T/1000 Base-X Combo
MES2324,
MES2324B
24x10/100/1000Base-T, 4x(10G Base-X(SFP+)/1000Base-X (SFP))
MES2324FB
20x1000 Base-X (SFP)
4x(10G Base-X(SFP+)/1000Base-X (SFP)
4x10/100/1000 Base-T/1000 Base-X Combo
MES2348B
48x10/100/1000Base-T, 4x(10G Base-X(SFP+)/1000Base-X (SFP))
MES2308
10x10/100/1000Base-T
2x1000Base-X(SFP)
