MES53xx, MES33xx, MES23xx Ethernet Switch Series 92
Spanning tree enabled mode RSTP
Default port cost method: short
Loopback guard: Disabled
Root ID Priority 32768
Address a8:f9:4b:7b:e0:40
This switch is the root
Hello Time 5 sec Max Age 38 sec Forward Delay 20 sec
Number of topology changes 0 last change occurred 23:45:41 ago
Times: hold 1, topology change 58, notification 5
hello 5, max age 38, forward delay 20
Interfaces
Name State Prio.Nbr Cost Sts Role PortFast Type
--------- -------- --------- -------- ------ ---- -------- -----------------
te1/0/1 enabled 128.1 100 Dsbl Dsbl No -
te1/0/2 disabled 128.2 100 Dsbl Dsbl No -
te1/0/5 disabled 128.5 100 Dsbl Dsbl No -
te1/0/6 enabled 128.6 4 Frw Desg Yes P2P (RSTP)
te1/0/7 enabled 128.7 100 Dsbl Dsbl No -
te1/0/8 enabled 128.8 100 Dsbl Dsbl No -
te1/0/9 enabled 128.9 100 Dsbl Dsbl No -
gi1/0/1 enabled 128.49 100 Dsbl Dsbl No -
Po1 enabled 128.1000 4 Dsbl Dsbl No -
5.16.6 G.8032v2 (ERPS) protocol configuration
ERPS (Ethernet Ring Protection Switching) is designed for increasing stability and reliability of data
transmission network having ring topology thanks to reducing network recovery time in case of
breakdown. The recovery time does not exceed 1 second, it is much lower than network changover time
when you use spanningtree protocols.
