ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 150
Show power supply status for all the device interfaces:
console# show power inline
Power-limit mode: Class based
Usage threshold: 95%
Trap: Disable
Legacy Mode: Disable
Inrush Test: Disable
SW Version: 22.172.3
Unit Module Nominal Consumed Temp (C)
Power (W) Power (W)
---- ------------ --------- ---------- --------
1 MES2308P 240 219 (91%) 85
12-port 1G
Managed
Switch with
8 POE+ ports
2 MES2308P 240 0 (0%) 42
12-port 1G
Managed
Switch with
8 POE+ ports
Interface Admin Oper Power (W) Class Device Priority
---------- ---------- ----------- ----------------- ----- -------------- --------
gi1/0/1 Auto On 31.800 4 low
gi1/0/2 Auto On 31.800 4 low
gi1/0/3 Auto On 31.0 4 low
gi1/0/4 Auto On 31.400 4 low
gi1/0/5 Auto On 31.500 4 low
gi1/0/6 Auto On 31.0 4 low
gi1/0/7 Auto On 31.600 4 low
gi1/0/8 Auto Fault 0.0 0 low
Show the power supply status of the chosen interface:
console# showpowerinlinegi1/0/1
Interface Admin Oper Power (W) Class Device Priority
---------- ---------- ----------- ----------------- ----- -------------- --------
gi1/0/1 Auto Searching 0.0 0 low
Port Status: Port is off. Detection is in process
Port standard: 802.3AT
Admin power limit (for port power-limit mode): 30.0 watts
Time range:
Operational power limit: 30.0 watts
Spare pair: Disabled
Negotiated power: 0 watts (None)
Current (mA): 0
Voltage(V): 0.0
Overload Counter: 0
Short Counter: 0
Denied Counter: 0
Absent Counter: 0
InvalidSignatureCounter: 0
Description of the displayed power supply parameters is shown in the Table 5.162– Parameters of the
power supply status.
Table 5.162– Parameters of the power supply status
Nominal Power
Nominal load supplying capacity of the PoE subsystem.
ConsumedPower
Measured value of the power consumption.
UsageThreshold
Power consumption threshold at which information message (snmp trap) about threshold
crossing is formed.
