ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 176
source
Source address
Specify the source IP address of the packet.
source_wildcard
Address mask of the source
The bit mask applied to the source IP address of the packet.
The mask defines the bits of the IP address which should be
ignored. “1” indicates an ignored bit. For example, the mask
can be used to specify an IP network that will be filtered out.
In order to add IP network 195.165.0.0 IP to a filtering rule,
the mask should be set to 0.0.255.255, i.e. the last 16 bits of
the IP address will be ignored.
destination
Destination address
Specify the destination IP address of the packet.
destination_wildcard
Address mask of the
destination
The bit mask applied to the destination IP address of the
packet. The mask defines the bits of the IP address which
should be ignored. “1” indicates an ignored bit. This mask is
used similarly to the source_wildcard mask.
vlan
Vlan ID
Specify the VLAN this rule will apply to.
dscp
The DSCP field in the L3
header
Specify the value of the diffserv DSCP field. Possible message
codes for the dscp field: (0 – 63).
precedence
IP priority
Define the priority of IP traffic: (0-7).
time_name
Name of the time-range
configuration profile
Specify configuration of time periods.
icmp_type
-
Type of ICMP messages used for ICMP packets filtering.
Possible message codes for the icmp_type field:echo-reply,
destination-unreachable, source-quench, redirect, alternate-
host-address, echo-request, router-advertisement, router-
solicitation, time-exceeded, parameter-problem, timestamp,
timestamp-reply, information-request, information-reply,
address-mask-request, address-mask-reply, traceroute,
datagram-conversion-error, mobile-host-redirect, mobile-
registration-request, mobile-registration-reply, domain_name-
request, domain_name-reply, skip, photuris, or the numeric
value of the message type (0 – 255).
icmp_code
ICMP message code
Code of ICMP messages used for ICMP packets filtering.
Possible message codes for the icmp_code field:(0 – 255).
igmp_type
IGMP message type
Type of IGMP messages used for IGMP packets filtering.
Possible message codes for the igmp_type field: host-query,
host-report, dvmrp, pim, cisco-trace, host-report-v2, host-
leave-v2, host-report-v3 or the numeric value of the message
type (0 – 255).
destination_port
UDP/TCP destination port
Possible values for the TCP port field: bgp (179), chargen (19),
daytime (13), discard (9), domain (53), drip (3949), echo (7),
finger (79), ftp (21), ftp-data (20), gopher (70), hostname (42),
irc (194), klogin (543), kshell (544), lpd (515), nntp (119), pop2
(109), pop3 (110), smtp (25), sunrpc (1110, syslog (514),
tacacs-ds (49), talk (517), telnet (23), time (37), uucp (117),
whois (43), www (80);
For an UDP port: biff (512), bootpc (68), bootps (67), discard
(9), dnsix (90), domain (53), echo (7 ), mobile-ip (434),
nameserver (42), netbios-dgm (138), netbios-ns (137), on500-
isakmp (4500), ntp (123), rip (520), snmp (161), snmptrap
(162), sunrpc (111), syslog (514), tacacs-ds (49), talk (517), tftp
(69), time (37), who (513), xdmcp (177).
Or a numeric value (0 – 65535).
source_port
UDP/TCP source port
list_of_flags
TCP flags
If you want to filter by a specific flag, put "+" before it;
otherwise put "-". Possible flags: +urg, +ack, +psh, +rst, +syn,
+fin, -urg, -ack, -psh, -rst, -syn and -fin. If you use multiple
flags for filtering, they are joined in one line without spaces.
For example: +fin-ack.
disable_port
Disable a port
Disable the port when receiving a packet from it that satisfies
the conditions of a deny command that describes that field.
log_input
Message log
Enable message log registration when a packet corresponding
to the entry is received.
