MES53xx, MES33xx, MES23xx Ethernet Switch Series 70
Source ports : te0/1
Receiver ports: te0/2,te0/4,te0/8
 Show information on protocol groups.
console# show vlan protocols-groups
Encapsulation Protocol Group Id
------------- ---------------- ----------------
0x800 (IP) Ethernet 1
0x806 (ARP) Ethernet 1
0x86dd (IPv6) Ethernet 3
 Show TenGigabitEthernet 0/1 port configuration:
console# show interfaces switchport TengigabitEthernet 0/1
Added by: D-Default, S-Static, G-GVRP, R-Radius Assigned VLAN, T-Guest VLAN, V-
Voice VLAN
Port : te1/0/1
Port Mode: Trunk
Gvrp Status: disabled
Ingress Filtering: true
Acceptable Frame Type: admitAll
Ingress UnTagged VLAN ( NATIVE ): 1
Protected: Disabled
Port is member in:
Vlan Name Egress rule Added by
---- -------------------------------- ----------- ----------------
1 1 Untagged D
2 2 Tagged S
3 3 Tagged S
4 4 Tagged S
5 5 Tagged S
6 6 Tagged S
8 8 Tagged S
28 28 Tagged S
Forbidden VLANS:
Vlan Name
---- --------------------------------
Classification rules:
Protocol based VLANs:
Group ID Vlan ID
------------ -------
Mac based VLANs:
Group ID Vlan ID
------------ -------
IP interface configuration
An IP interface is created when an IP address is assigned to any of the interfaces of the device,
gigabitethernet, tengigabitethernet, fortygigabitethernet, oob, port-channel, or VLAN.
Command line prompt in the IP interface configuration mode is as follows.
console# configure
console(config)# interface ip A.B.C.D
