ELTEX MES23xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 88
spanning-tree process id
id: (1..31)/0
Command creats a specific process and translate the
command interface in its configuration mode.
Commands listed above are applied within the
process:
spanning-tree forward-time seconds;
spanning-tree hello-time seconds ;
spanning-tree max-age seconds ;
spanning-tree priority prior_val
no spanning-tree process id
Delete a specified process.
If you set the STP parameters forward-time, hello-time, max-age, make sure that:
2*(Forward-Delay - 1) >= Max-Age >= 2*(Hello-Time + 1).
Ethernet or port group interface configuration mode commands
Command line prompt in the Ethernet or port group interface configuration mode is as follows:
console(config-if)#
Table 5.72. Ethernet or port group interface configuration mode commands
Command
Value/Default value
Action
spanning-tree disable
-/enabled
Disable STP on the interface.
no spanning-tree disable
Enable STP on the interface.
spanning-tree cost cost
cost:
(1..200000000)/seeTable
5.69
Set the cost of a path through this interface.
- cost – path cost.
no spanning-tree cost
Set the cost based on the port transfer rate and the method of
determining path cost, see Table 5.65. Ethernet interface and
interface group configuration mode commands
spanning-tree port-priority
priority
priority: (0..240)/128
Set the interface priority in the STP spanning tree.
Priority value must be divisible by 16.
no spanning-tree
port
Set the default value.
spanning-tree portfast
[auto]
-/disabled
Specify the mode in which the port immediately switches to
transmission mode when the link is established, before the
timer expires.
- auto- add 3 second delay before entering the transmission
mode.
no spanning-tree portfast
Enable immediate transition into the transmission mode when
the link is established.
spanning-tree guard root
-/protection disabled
Enable root protection for all STP spanning trees for the
selected port. This protection prohibits the interface to be the
root port of the switch.
no spanning-tree guard
root
Set the default value.
spanning-tree bpduguard
{enable | disable}
-/protection disabled
Enable protection that disables the interface when a BPDU
packet is received.
no spanning-tree
bpduguard
Disable protection that disables the interface when a BPDU
packet is received.
spanning-tree link-type
{point-to-point | shared}
-/'point-to-point' for a
duplex port, 'shared' for a
half-duplex port
Set the RSTP state to 'forwarding' and defines the link type for
a given port:
- point-to-point - point to point;
- shared - shared.
no spanning-tree link-type
Set the default value.
spanning-tree bpdu
{filtering | flooding}
-
Set the BPDU packet processing mode by the interface on
which STP is disabled.
- filtering - BPDU packets are filtered on the interface on
which STP is disabled;
- flooding - untagged BPDU packets are transmitted and
tagged packets are filtered on the interface on which STP is
disabled.
no spanning-tree bpdu
Set the default value.
