MES53xx, MES33xx, MES23xx Ethernet Switch Series 95
packets before dropping them.
This value will be transmitted to the receiving side in the LLDP
update packets; and should be an increment for the LLDP
timer. Thus, the LLDP packet lifetime is calculated by the
formula: TTL = min(65535, LLDP-Timer * LLDP-HoldMultiplier)
no lldp hold-multiplier
Set the default value.
lldp reinit seconds
seconds: (1..10)/2 seconds
Minimum amount of time for the LLDP port to wait before
LLDP reinitialization.
no lldp reinit
Set the default value.
lldp tx-delay seconds
seconds: (1..8192)/2
seconds
Specify the delay between the subsequent LLDP packet
transmissions caused by the changes of values or status in the
local LLDP MIB database.
It is recommended that this delay be less than
0.25* LLDP-Timer.
no lldp tx-delay
Set the default value.
lldp lldpdu {filtering |
flooding}
-/filtering
Specify the LLDP packet processing mode when LLDP is
disabled on the switch:
- filtering - LLDP packets are filtered if LLDP is disabled on the
switch
- flooding - LLDP packets are transmitted if LLDP is disabled on
the switch
no lldp lldpdu
Set the default value.
lldp med fast-start
number
number: (1..10)/3
Set the number of PDU LLDP repetitions for quick start defined
by LLDP-MED.
no lldp med fast-start
repeat-count
Set the default value.
lldp med network-policy
number application [vlan
vlan_id] [vlan-type {tagged |
untagged}] [up priority] [dscp
value]
number: (1..32);
application: (voice,
voice-signaling,
guest-voice,
guest-voice-signaling,
softphone-voice,
video-conferencing,
streaming-video,
video-signaling);
vlan_id: (0..4095);
priority: (0..7);
value: (0..63)
Specify a rule for the network-policy parameter (device
network policy). This parameter is optional for the LLDP MED
protocol extension.
- number - sequential number of a network policy rule;
- application - main function defined for this network policy
rule;
- vlan_id - VLAN identifier for this rule;
- tagged/untagged - specify whether the VLAN used by this
rule is tagged or untagged;
- priority - the priority of this rule (used on the second layer of
OSI model);
- value - DSCP value used by this rule;
no lldp med network-policy
number
Remove the created rule for the network-policy parameter.
lldp notifications interval
seconds
seconds: (5..3600)/5
seconds
Specify the maximum LLDP notification transfer rate.
- seconds - time period during which the device can send at
most one notification;
no lldp notifications interval
Set the default value.
Ethernet interface configuration mode commands:
Command line prompt in the Ethernet interface configuration mode is as follows:
console(config-if)#
Table 5.84. Ethernet interface configuration mode commands
Command
Value/Default value
Action
lldp transmit
By default, can be used in
both directions.
Enable packet transmission via LLDP on the interface.
no lldp transmit
Disable packet transmission via LLDP on the interface.
lldp receive
Enable the interface to receive packets via LLDP.
no lldp receive
Disable the interface to receive packets via LLDP.
lldp optional-tlv tlv_list
tvl_list: (port-desc, sys-
name, sys-desc, sys-cap,
802.3-mac-phy, 802.3-lag,
802.3-max-frame-size)/By
default optional TLV are
not included in the packet.
Specify which optional TLV fields (Type, Length, Value) to be
included into the LLDP packet by the device.
You can pass up to 5 optional TLV to the command.
no lldp optional-tlv
Set the default value.
