ELTRA CS-2000 - Infrared Electronics

Service
100
Fig.
83
: The tubing
When reinstalling the infrared cell unit in the analyzer, pay attention to the color markings of the
tubes and their fittings.
Pos: 7.4 /0025 Ü berschriften/ELTR A 1.1 Übersc hriften/11 Infrar ed electronics E LTRA @ 6\ mod_136964082 1864_9.doc x @ 42223 @ 2 @ 1
5.2 Infrared electronics
Pos: 7.5 /0010 ELTRA/0015 ser vice_instructions /CS-2000_ser vice/15 Ser vice_CS-2000/151 0 Modul IR-elec tronics @ 9\ mod_1425543339 476_9.docx @ 74718 @ 33 @ 1
5.2.1 Removing the IRC-board
Fig.
84
: IRC 1.4+
