EMC VNX5300 - VNX5300 DAE 2 U Leds; 2 U, 25 Disk-Array Enclosure; Front and Rear View

29
VNX5300 DAE 2U LEDs
0
24
Disk drive
power/activity
LED
Disk-array enclosure
status/fault LED
Disk-array enclosure
Power LED
Front
Disk drive
Fault LED
2U, 25 Disk-array enclosure
6 Gb SAS
X4
#
6 Gb SAS
X4
#
Enclosure
identification
Enclosure
identification
LCC A
power supply
LED
LCC A
power supply
fault LED
Rear
A
B
LCC B
power supply
LED
LCC B
power supply
fault LED
For complete information on the DAE LEDs, see the VNX5300 Hardware Overview.
