EMC VNX5300 - Cabling; Cable Label Wraps

75
VNX5300 bezels
1. Ensure that the screws holding the components in place are fi rmly tightened.
2. After all the components are installed and the cabling is securely in place, snap on the
bezels.
Control Station
DVD
DV
D
DVD
DVD
Control Station
Standby power supply
Disk processor enclosure
Blade enclosure
A
A
C
A
C
AC
A
C
B
Front
