Emerson Process Management GmbH & Co. OHGA-16
X-STREAM XEFD
Instruction Manual
HASXEDE-IM-EX
03/2012
A.3 CSA Certicate of Compliance
Certificate:
1714037 (LR 105173)
Master Contract:
185562
Project:
2507282
Date Issued:
March 14, 2012
DQD 507 Rev. 2009-09-01 Page: 5
u = Gas Path Fittings: E, F, G, H, I, J, K or L
v = Flame Arrestors: 2, 3, 4, 5, 6, 7 or 8
X-STREAM FD (XEFD): Flameproof for Hazardous Locations
Class I, Zone 1, Ex d IIB+H2, T3 and/or Class I, Division 2, Groups B, C, and D, T3
Class I, Zone 1, AEx d IIB+H2, T3 and/or Class I, Division 2, Groups B, C, and D, T3
Gas analyzer , Model: X-STREAM, rated 100-240Vac, 50/60 Hz, 3 - 1.5A, Class I, Pollution Degree II;
Ambient Temperature Range: -30°C to +50°C
X-STREAM FD Enhanced (XEFD) has same electronics as the X-STREAM Enhanced General Purpose Gas
Analyzer (XEF) with same Hazardous Locations Enclosure as X-STREAM X2FD.
XEFD-abcdefghijklmnopqrstuv
a = Language: A, B, C, D, E, F or G
b = Ambient Conditions: 1 or 4
c = Instrument: 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11, 12, 13, 14 or 15
d = Bench 1: any combination of 2 or 3 alpha-numeric characters
e = Bench 1 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
f = Bench 2: any combination of 2 or 3 alpha-numeric characters
g = Bench 2 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
h = Bench 3: any combination of 2 or 3 alpha-numeric characters
i = Bench 3 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
j = Bench 4: any combination of 2 or 3 alpha-numeric characters
k = Bench 4 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
l = Enclosure: 1, 2, 3 or 4
m = Hazardous Area Options and Special Approvals: B or D
B = CSA Certification
To Next Page
