Emerson Rosemount Xstream Series Instruction Manual Addendum

Emerson Process Management GmbH & Co. OHG3-6
X-STREAM XEFD
Instruction Manual
HASXEDE-IM-EX
03/2012
3.5.3 Keys
Six keys enable the use of the menu system.
Depending on the operational mode (measu-
ring, browsing menus, editing) they have the
following functions:
enter key:
Mode Function
Measuring Enter main menu
Browsing
Open submenu (..) or
execute command (!)
Editing Conrm new entry
home key:
Mode Function
Measuring (no function)
Browsing Return to measurement display
Editing Abort entry
up / down keys:
Mode Function
Measuring Enter main menu
Browsing
Highlight next menu line
Open the previous/next page,
when currently a line beginning
with / is highlighted
Editing Change current parameter
3.5 Front Panel Elements
