Emerson Rosemount Xstream Series Instruction Manual Addendum

Emerson Process Management GmbH & Co. OHG1-20
X-STREAM XEFD
Instruction Manual
HASXEDE-IM-EX
03/2012
1.9 Vapor Recovery Application
Converter efciency
The measurement accuracy is highly depen-
dent on the converter efciency: If this is too
low, the converter material needs replace-
ment.
To measure the converter efciency, one
has to compare the measurement values of
CH1 with and without having the gas owing
through the converter. This requires activating
the valve V1.
For the ease of use, special PLC and calcu-
lator programs are provided with analyzers
for vapor recovery applications, automatically
calculating the efciency each time after a ca-
libration has been performed. The calculated
value shows up as a measurement result on
the measurement display.
To calculate the efciency without a prece-
ding calibration, you can also start the PLC
program manually from the webbrowser
interface.
4 Maintenance section of this manual for
instructions about when and how to replace
the converter material. The appendix contains
listings of the PLC and calculator programs,
enabling automatic converter efciency cal-
culation.
