4.4 Manual Calibration
When nished, press left several times to re-
turn to SELECT COMPONENT (multi channel
analyzer only), to perform a span calibration
for another channel,
or
press home to return to the MEASUREMENT
SCREEN, to nish with manual calibration
procedures.
4.4.2 Manual Span Calibration
Multi-channel unit:
Select the channel to be calibrated in
SELECT COMPONENT.
Before selecting any further line
make sure the required calibra-
tion gas is applied and owing!
SPAN CALIBRATION offers the similiar opti-
ons as ZERO CALIBRATION.
Select "Span Calibration.."
Span Calibration
Cancel!
Start!
Span Gas 0.000 ppm
Concentration 0.000 ppm
Flow 0.00 l/min
Status..
Results..
Restore..
