©2020 EMS Ltd. All rights reserved. Page 16 of 80 MK067-0001-99 (Issue 1) 04/11/2020 AJM
FIRE
FAULT
POWER
FUNCTION 1
FUNCTION 2
1
2
3
4
Intelligent Wireless Zone Monitor
WZM fascia
The WZM provides status information via the display and status lamps. The WZM’s functions are achieved via
the entry of a user access code.
The WZM’s features are shown below.
3
1
2
4
1
3
Status LEDs
2
Function buttons
4
80 character display
Navigation & confirmation buttons
